12V 100Ah Smart Lithium Iron Phosphate Battery
hogar

Batería de litio de 12 V

12V 100Ah Smart Lithium Iron Phosphate Battery

12V 100Ah Smart Lithium Iron Phosphate Battery

C&D Emerging Energy proudly presents its 12V lithium iron phosphate (LiFePO₄) battery module, built in the industry-standard BCI Group 31 size. This compact yet powerful battery is an ideal solution for a wide range of deep-cycle applications — including recreational vehicles (RVs), boats, trucks, remote cabins, and other off-grid setups. Designed as a direct replacement for traditional deep-cycle lead-acid batteries, it offers significantly improved performance, longevity, and efficiency.The battery features robust internal protection against common electrical issues such as under-voltage, over-voltage, over-current, over-temperature, under-temperature, short circuits, and system errors. These intelligent safeguards ensure safe and stable operation in demanding environments. In addition, the battery supports advanced management functions, including precise State of Charge (SoC) monitoring and automatic cell balancing, helping users maintain optimal performance and extend the battery’s service life.With its durable design and intelligent control, this 12V LiFePO₄ battery delivers reliable, maintenance-free energy — making it the perfect power companion for life on the road, on the water, or off the grid.





Electrical Specifcation
Nominal Voltage 12.8 VDC
Nominal Capacity 100 Ah
Resistance <10 mΩ
Self Discharge ≤3% per month
Max. Batteries in Parallel or Series 4S4P/IS16P
Cycle Life (25°c) >4500 (80% DOD, 0.5 C, 25 °C)
Design Life ≥10 years
Short Circuit Current Duration <1 kA/100 us
Discharge of Depth (DoD) 100%
Discharge Specifcation
Max. continuous Discharging current 100 A
Peak Discharging current 200 A @30 s
Charge Specifcation
Recommended Charging Current 50 A
Max. Continuous Charging Curent 100 A
Recommended Charging Voltage 14 V~14.8 V
Environment Specifcation
Storage Temperature  -4℉~140℉(-20°C~60℃)
Operating Temperature  -4℉~122℉(20°C~50°C
*The battery does not support charging when the temperature is below 32 'F (0 °C)
Max. Altitude 13123 ft (4000 m)
Relative Humidity 5%~95% (non-condensing)
Mechanical Specifcation
Dimensions (LxWxH) 12.8 in x 6.83 in x 937 in (325 mm x 173.5 mm x 238 mm)
Weight Approx. 26.46 lbs (12 kg)
Terminal Type M8
Terminal Torque 9 ±1N-m
Case Material PC
IP Rating IP67
Cell Type-chemistry LiFePO4
Communication BLE 5.0



UN38.3, TELEC, FCC, IEC 62619, Bluetooth SIG





  • High Reliability--

the built-in advanced BMS manages charging and discharging status, helps in balancing the individual cells, and ensures intelligent automatic protection against over-voltage, under-voltage, over-current, over-temperature, under-temperature and short circuit.



  • High Energy Density—

With the high energy density lithium cells, our battery is half the weight of the lead acid battery of equivalent energy, and 70% the size of the regular lithium battery of equivalent energy. It's easier to carry, faster to charge, and more convenient to use.



  • Real-time Monitoring via App—

The built-in Bluetooth module allows real-time monitoring via mobile devices.



  • Low Self-discharge Loss—

The battery can be stored for up to 6 months if it is turned off after being fully discharged, and can be stored for up to 12 months if it is turned off when its level is between 40% and 70%.



  • Flexible Connection in Parallel and Series—

The battery supports up to 16 identical batteries in 4S4P/1S16P connection, building a battery system with a max. energy output of 20.48 kWh.



  • Communication Expansion—

With a KIT-C1 communication box, you can form a battery network to extend external communication and control functions of these batteries, such as CAN communication, RS485 communication, and dry contacts
