1000W~3000W Pure Sine Wave Inverter

C&D Emerging Energy’s pure sine wave inverter delivers stable, high-quality power output that ensures reliable performance across a wide range of devices. Whether you're powering a coffee machine, microwave, television, satellite system, printer, or other heavy-duty equipment, this inverter provides clean energy that mimics the electricity from the grid. It's the ideal solution for operating both household appliances and sensitive office electronics, offering consistent performance and protecting your devices from power fluctuations or damage.

MODEL		SCH1000	SCH1500	SCH2000	SCH3000
Output Power		1000W	1500W	2000W	3000W
Input Current(MAX DCAmps)		30A	60A	100A	150A
Surge Power		2000W	3000W	4000W	6000W
Dc Input Voltage		12, 24 or 48 VDC
DC input Regulation		10.5-15 VDC (x2 for 24 VDC: x4 for 48 VDC)
Output Voltage		100/110/120VAC+/-3%: 220/230/240VAC+1-5%
Output Frequency		50/60Hz+/-0.05%
Output Waveform		True sine wave THD<3%
AC Input Voltage		100/110/120VAC+/-3%:220/230/240VAC+/-5%
AC Input Frequency		50/60Hz+/-0.05%
Power Factor		0.8-1
Efficiency	110V	92%	92%	93%	92%
	230V	93%	93%	93%	93%
CONTROL & SIGNALINDICATES
Fault indication		Red LED light and buzz alarm
Work indication		Green LED light
Remote Control		CR10 or CR11(work with DBs battery isolator)
Battery type		AGM, Seal lead acid, Gel, open lead acid, LifeO4
Protection		Overload, Over/under input voltage, Over temperature, Short circuit
Safety		AS/ NZS 4763:2011. UL458, LVD(EN60950)
GENERAL PARAMETER
Operating Temp		-10~45°C
Working Humidity		20%~90% RH
Storage Temp		-30-70°C
Cooling		Automatic temp-control fans
Weight (kg)		3.2	3.5	4.6	5.8
Size( mm)		376254119	416254119	457.5254119	572254119
